How to Attach TV to Wall Mount? Step-by-Step Guide

Mounting your TV on the wall not only saves space but also creates a sleek, modern look. If you're wondering how to attach TV to wall mount safely and correctly, this guide is for you.

Whether you're using a fixed, tilting, or full-motion wall mount, this tutorial will walk you through every step — even if you're a beginner.

What You’ll Need Before You Start​

Before you start mounting your TV, make sure you have:

Tools:

• Power drill with drill bits
• Stud finder
• Level
• Screwdriver
• Socket wrench
• Pencil
• Tape measure

Hardware:

• TV wall mount bracket (VESA compatible)
• Screws, washers, and wall anchors (usually included)
• Mounting template (optional, often provided)

Pro Tip: Check your TV’s VESA size (e.g., 200x200, 400x400) to match with the correct mount.

Step-by-Step: How to Attach TV to Wall Mount​

Step 1: Choose the Right Wall Location​

• Use a stud finder to locate wood studs (don’t mount directly into drywall).
• Mark the stud centers with a pencil.
• Decide the height — ideally, the TV should be eye-level when seated.

Standard mounting height is around 42 inches from the floor to the center of the screen.

Step 2: Attach the Wall Mount Bracket to the Wall​

1. Align the wall plate of your mount with the studs.
2. Use a level to ensure it's straight.
3. Drill pilot holes into the stud marks.
4. Secure the wall plate with lag bolts using a socket wrench.

Don’t overtighten — this can strip the studs or bend the mount.

Step 3: Attach the Mounting Arms to the TV​

1. Lay the TV face down on a soft surface (blanket or foam).
2. Locate the VESA mounting holes on the back.
3. Align the mounting arms and screw them in securely using the provided bolts and washers.

If your mount is tilting or full-motion, check for adjustable tension knobs and set your preferred tilt now.

Step 4: Mount the TV on the Wall Plate​

1. Lift the TV carefully (you may need two people).
2. Align the mounting arms with the wall plate hooks or rails.
3. Gently hook the TV onto the wall bracket.
4. Secure the locking mechanism (clips or screws underneath, depending on the model).

Double-check that the TV is fully latched to prevent accidental falls.

Bonus: Cable Management Tips​

Once the TV is mounted:

• Use adhesive cable clips or a cord cover kit to hide visible cables.
• Consider routing cables through the wall using an in-wall power/cable kit (ensure it meets local codes).
• Use zip ties or Velcro straps to bundle excess wires.

Troubleshooting & FAQs​

Problem	Solution
TV feels loose after mounting	Ensure all screws are tight and the locking mechanism is engaged
Mounting holes don’t line up	Double-check VESA compatibility
No studs in the ideal spot	Use a professional-grade anchor system or consult a contractor
Can’t lift TV safely	Ask a second person to help – never mount alone

Final Thoughts​

Learning how to attach a TV to a wall mount is easier than it looks. With the right tools, careful measurements, and a bit of patience, you’ll have your screen mounted securely in under an hour.
